Self Adhesive Seal - RP74 (2250mm)

Key Points:

• Door Brush Strip - Raven RP74.
• Can be mounted to the inside or outside of door head and bottom face.
• For single, double or sliding doors.
•  Symbol Guide

Description:
A nylon brush strip seal with a self adhesive aluminium holder. Mounted to the inside or outside door head and bottom face, RP74 provides a very neat sealing solution with the advantage of final on site installation which overcomes unforeseen floor or sill variation.

We suggest using strip in conjunction with Raven Theshold Plates.

Specification:

• Location: Frames or bottoms of single, double, sliding and double acting doors.
• Min/Max Gap: Up to 13mm (user determined).
• Fixing: Self adhesive or can be screw fixed. Note: Contact surface must be clean, smooth and if painted, well cured. Self adhesive seals will not adhere to oiled or alkyd finishes or to easy clean wash and wear paint surfaces.
• Finish: Satin clear (silver).
• Seal Size: 2250mm lengths
