Expansion Joint Seals
Intumescent Expansion Joint Seals
Fire Rated Expansion Joint Seal / Linear Joint Seal. Available up to 150mm gap size. Joint movement capability of +/- 25%. Tested in accordance with BS 476 Part 20: 1987. IET (IEE) 17th Edition Fire Stop Compliant to Regulation 527.1-3 - Electrical Installations. BS 7671-2008 Chapter 42 & 52 - Electrical Installations Fire Resistance. Acoustic Isolation to EN 10140 to 22dB. Highly flexible and water resistant. Air Permeability testing to EN 1026 to 600Pa - 100Pa 3.3/1.7 m3/h/m2 with FLEXI COAT. Maintenance free.
Ordering Example:
To specify for a gap width of 20mm order Gap Width Dimension 11mm to 20mm. In the shopping basket set the number of one metre lengths you require. Supplied by the metre.
Fire Rated Expansion Joint Seal / Linear Joint Seal | Seal: Width 12mm Depth 12mm | Tested in accordance with BS 476 Part 20: 1987.
Fire Rated Expansion Joint Seal / Linear Joint Seal | Seal: Width 29mm Depth 12mm | Tested in accordance with BS 476 Part 20: 1987.
Fire Rated Expansion Joint Seal / Linear Joint Seal | Seal: Width 32mm Depth 20mm | Tested in accordance with BS 476 Part 20: 1987.
Fire Rated Expansion Joint Seal / Linear Joint Seal | Seal: Width 53mm Depth 20mm | Tested in accordance with BS 476 Part 20: 1987.
Fire Rated Expansion Joint Seal / Linear Joint Seal | Seal: Width 61mm Depth 35mm | Tested in accordance with BS 476 Part 20: 1987.
Fire Rated Expansion Joint Seal / Linear Joint Seal | Seal: Width 84mm Depth 40mm | Tested in accordance with BS 476 Part 20: 1987.
Fire Rated Expansion Joint Seal / Linear Joint Seal | Seal: Width 90mm Depth 50mm | Tested in accordance with BS 476 Part 20: 1987.
Fire Rated Expansion Joint Seal / Linear Joint Seal | Seal: Width 126mm Depth 100mm | Tested in accordance with BS 476 Part 20: 1987.
Fire Rated Expansion Joint Seal / Linear Joint Seal | Seal: Width 147mm Depth 125mm | Tested in accordance with BS 476 Part 20: 1987.
Fire Rated Expansion Joint Seal / Linear Joint Seal | Seal: Width 170mm Depth 100mm | Tested in accordance with BS 476 Part 20: 1987.
