Door Bottom Seals

Door Bottom Seal - RP30 (2250mm)

Door Bottom Seal - RP30 (2250mm)

£29.06 £24.22 (ex. VAT)
Concealed heavy duty sweep action seal - fitted in a morticed groove | Min/Max Gap: 5/20mm | 2250mm stock lengths

FREE DELIVERY on orders over £600 (£500 ex. VAT)*
*excluding Boards, Batts, Mortar products and the following postcodes IM, HS, ZE, JE, GY, KW, FK, PH33 or AB


Key Points:

  • The RP30 a concealed heavy duty sweep action seal.
  • Raven icons Symbol Guide

The RP30 is a heavy duty sweep/compression seal. The RP30 is fitted into a concealed, machined groove that should be deep enough to allow packing for adjustment. Forms a weather seal when used with Raven RP13 or RP82 threshold plates.


  • Location: Bottom of doors, meeting stiles or user determined bumper strip.
  • Min/Max Gap: 3mm to 8mm (user determined).
  • Finish: Satin clear (silver).
  • Fixing: Concealed screw fix. Zinc plated, cross recess head S.T. screws supplied.
  • Seal: RP330. Black EPDM.
  • Seal Sizes Available: in 2250mm stock lengths.
  • Product Code:
  • MPN:
